Diesel generator
Yangdong
Standard features
- Preheater
- Battery and cables
- Electronic battery charger
- Fuel tank integrated into the chassis
- Flexible fuel hoses and oil drain valve
- Welded steel sheet chassis, coated with electrostatic powder
- Galvanized stainless steel enclosure
Optional features
- Soundproof enclosure
- Transfer panel
- Fuel water separator filter
- Alternator output switch
- Fuel tank heater
- Oil-based heater
- External fuel tank and transfer pump
- Remote monitoring and control system
- Synchronization systems
- Special exhaust noise damper
- Trailer
Yangdong
Generator models
Yangdong
Enclosure
Enclosure characteristics
Generator chassis are made of steel and feature a special modular design. The fuel tank is mounted on the chassis. Connections for the alternator, engine, and radiator are made with supports to minimize vibrations. Upon request, we can create special models of chassis and fuel tanks.
Features:
- Emergency stop button
- Window for the control panel
- Special sound insulation
- Exhaust pipe
- Special air ducts for cooling
- Corrosion and rust-resistant electrostatic paint
Control panel
The generator control panels are user-friendly, robust, with good long-term durability, and can be upgraded with secure software. Optionally, they can be remotely controlled via ETHERNET and GPRS. The panel body is made of steel sheet and coated with electrostatic paint. The electronics have an insulated and waterproof design.
Features:
- Automatic control system with LCD screen
- Remote monitoring and control capability
- Multifunctional business opportunity
- Language change capability
- Programmable via USB, RS-232, and GSM
Output values
Stendby power:
| kVA | kW | Engine Speed (rpm) |
|---|---|---|
| 15 | 12 | 1500 |
Power:
| kVA | kW | Engine Speed (rpm) |
|---|---|---|
| 13.6 | 10.9 | 1500 |
Diesel engine
State-of-the-art engine brands that comply with ISO 8528, ISO 3046, BS 5514, DIN 6271 standards, have low fuel consumption, are mounted on the fuel pump, and have mechanical or electronic type governors are used.
| Brand | Yang Dong |
| Model | YD385D |
| Air Intake System | Naturally aspirated |
| Cylinder capacity (l) | 1.5 |
| Cylinder Array | 3 in linie |
| Bore x Stroke (mm*mm) | 85*90 |
| Governor Type | Mechanical/Electronic |
Dimensions and weight
Enclosed Group:
| Width (mm) | 950 |
| Length (mm) | 2000 |
| Height (mm) | 1260 |
| Weight (Kg) | 650 |
| Fuel Tank Capacity (l) | 85 |
Open Group:
| Width (mm) | 950 |
| Length (mm) | 1700 |
| Height (mm) | 1100 |
| Weight (Kg) | 456 |
| Fuel Tank Capacity (l) | 85 |
Output values
Stendby power:
| kVA | kW | Engine Speed (rpm) |
|---|---|---|
| 22 | 17.6 | 1500 |
Power:
| kVA | kW | Engine Speed (rpm) |
|---|---|---|
| 20 | 16 | 1500 |
Diesel engine
State-of-the-art engine brands that comply with ISO 8528, ISO 3046, BS 5514, DIN 6271 standards, have low fuel consumption, are mounted on the fuel pump, and have mechanical or electronic type governors are used.
| Brand | Yang Dong |
| Model | YD485D |
| Air Intake System | Naturally aspirated |
| Cylinder capacity (l) | 2.1 |
| Cylinder Array | inline-four |
| Bore x Stroke (mm*mm) | 85*95 |
| Governor Type | Mechanical/Electronic |
Dimensions and weight
Enclosed Group:
| Width (mm) | 950 |
| Length (mm) | 2000 |
| Height (mm) | 1260 |
| Weight (Kg) | 733 |
| Fuel Tank Capacity (l) | 85 |
Open Group:
| Width (mm) | 950 |
| Length (mm) | 1700 |
| Height (mm) | 1100 |
| Weight (Kg) | 545 |
| Fuel Tank Capacity (l) | 85 |
Output values
Stendby power:
| kVA | kW | Engine Speed (rpm) |
|---|---|---|
| 25 | 18 | 1500 |
Power:
| kVA | kW | Engine Speed (rpm) |
|---|---|---|
| 22.5 | 20 | 1500 |
Diesel engine
State-of-the-art engine brands that comply with ISO 8528, ISO 3046, BS 5514, DIN 6271 standards, have low fuel consumption, are mounted on the fuel pump, and have mechanical or electronic type governors are used.
| Brand | Yang Dong |
| Model | YND485D |
| Air Intake System | Naturally aspirated |
| Cylinder capacity (l) | 2.21 |
| Cylinder Array | inline-four |
| Bore x Stroke (mm*mm) | 85*100 |
| Governor Type | Mechanical |
Dimensions and weight
Enclosed Group:
| Width (mm) | 800 |
| Length (mm) | 2000 |
| Height (mm) | 1200 |
| Weight (Kg) | 585 |
| Fuel Tank Capacity (l) | 40 |
Open Group:
| Width (mm) | 800 |
| Length (mm) | 1700 |
| Height (mm) | 1100 |
| Weight (Kg) | 480 |
| Fuel Tank Capacity (l) | 40 |
Output values
Stendby power:
| kVA | kW | Engine Speed (rpm) |
|---|---|---|
| 28 | 22.4 | 1500 |
Power:
| kVA | kW | Engine Speed (rpm) |
|---|---|---|
| 25.4 | 20.3 | 1500 |
Diesel engine
State-of-the-art engine brands that comply with ISO 8528, ISO 3046, BS 5514, DIN 6271 standards, have low fuel consumption, are mounted on the fuel pump, and have mechanical or electronic type governors are used.
| Brand | Yang Dong |
| Model | YSD490D |
| Air Intake System | Naturally aspirated |
| Cylinder capacity (l) | 2.5 |
| Cylinder Array | inline-four |
| Bore x Stroke (mm*mm) | 90*100 |
| Governor Type | Mechanical/Electronic |
Dimensions and weight
Enclosed Group:
| Width (mm) | 950 |
| Length (mm) | 2000 |
| Height (mm) | 1260 |
| Weight (Kg) | 795 |
| Fuel Tank Capacity (l) | 85 |
Open Group:
| Width (mm) | 950 |
| Length (mm) | 1700 |
| Height (mm) | 1100 |
| Weight (Kg) | 600 |
| Fuel Tank Capacity (l) | 85 |
Output values
Stendby power:
| kVA | kW | Engine Speed (rpm) |
|---|---|---|
| 34 | 27.2 | 1500 |
Power:
| kVA | kW | Engine Speed (rpm) |
|---|---|---|
| 30.9 | 24.7 | 1500 |
Diesel engine
State-of-the-art engine brands that comply with ISO 8528, ISO 3046, BS 5514, DIN 6271 standards, have low fuel consumption, are mounted on the fuel pump, and have mechanical or electronic type governors are used.
| Brand | Yang Dong |
| Model | Y495D |
| Air Intake System | Naturally aspirated |
| Cylinder capacity (l) | 2.9 |
| Cylinder Array | inline-four |
| Bore x Stroke (mm*mm) | 95*105 |
| Governor Type | Mechanical/Electronic |
Dimensions and weight
Enclosed Group:
| Width (mm) | 950 |
| Length (mm) | 2000 |
| Height (mm) | 1260 |
| Weight (Kg) | TBA |
| Fuel Tank Capacity (l) | 85 |
Open Group:
| Width (mm) | 950 |
| Length (mm) | 1700 |
| Height (mm) | 1100 |
| Weight (Kg) | TBA |
| Fuel Tank Capacity (l) | 85 |
Output values
Stendby power:
| kVA | kW | Engine Speed (rpm) |
|---|---|---|
| 45 | 36 | 1500 |
Power:
| kVA | kW | Engine Speed (rpm) |
|---|---|---|
| 40.9 | 32.7 | 1500 |
Diesel engine
State-of-the-art engine brands that comply with ISO 8528, ISO 3046, BS 5514, DIN 6271 standards, have low fuel consumption, are mounted on the fuel pump, and have mechanical or electronic type governors are used.
| Brand | Yang Dong |
| Model | Y4105D |
| Air Intake System | Naturally aspirated |
| Cylinder capacity (l) | 4.1 |
| Cylinder Array | inline-four |
| Bore x Stroke (mm*mm) | 105*118 |
| Governor Type | Mechanical/Electronic |
Dimensions and weight
Enclosed Group:
| Width (mm) | 950 |
| Length (mm) | 2300 |
| Height (mm) | 1560 |
| Weight (Kg) | TBA |
| Fuel Tank Capacity (l) | 85 |
Open Group:
| Width (mm) | 950 |
| Length (mm) | 2000 |
| Height (mm) | 1310 |
| Weight (Kg) | TBA |
| Fuel Tank Capacity (l) | 85 |
Output values
Stendby power:
| kVA | kW | Engine Speed (rpm) |
|---|---|---|
| 55 | 44 | 1500 |
Power:
| kVA | kW | Engine Speed (rpm) |
|---|---|---|
| 50 | 40 | 1500 |
Diesel engine
State-of-the-art engine brands that comply with ISO 8528, ISO 3046, BS 5514, DIN 6271 standards, have low fuel consumption, are mounted on the fuel pump, and have mechanical or electronic type governors are used.
| Brand | Yang Dong |
| Model | Y4102ZLD |
| Air Intake System | Turbocharger, Intercooler |
| Cylinder capacity (l) | 3.8 |
| Cylinder Array | inline-four |
| Bore x Stroke (mm*mm) | 102*118 |
| Governor Type | Mechanical/Electronic |
Dimensions and weight
Enclosed Group:
| Width (mm) | 950 |
| Length (mm) | 2300 |
| Height (mm) | 1560 |
| Weight (Kg) | TBA |
| Fuel Tank Capacity (l) | 85 |
Open Group:
| Width (mm) | 950 |
| Length (mm) | 2000 |
| Height (mm) | 1310 |
| Weight (Kg) | TBA |
| Fuel Tank Capacity (l) | 85 |
Output values
Stendby power:
| kVA | kW | Engine Speed (rpm) |
|---|---|---|
| 60 | 48 | 1500 |
Power:
| kVA | kW | Engine Speed (rpm) |
|---|---|---|
| 54 | 43 | 1500 |
Diesel engine
State-of-the-art engine brands that comply with ISO 8528, ISO 3046, BS 5514, DIN 6271 standards, have low fuel consumption, are mounted on the fuel pump, and have mechanical or electronic type governors are used.
| Brand | Yang Dong |
| Model | Y4102ZLD |
| Air Intake System | Turbocharger, Intercooler |
| Cylinder capacity (l) | 3.875 |
| Cylinder Array | inline-four |
| Bore x Stroke (mm*mm) | 102*118 |
| Governor Type | Mechanical/Electronic |
Dimensions and weight
Enclosed Group:
| Width (mm) | 1000 |
| Length (mm) | 2300 |
| Height (mm) | 1545 |
| Weight (Kg) | 932 |
| Fuel Tank Capacity (l) | 101 |
Open Group:
| Width (mm) | 1000 |
| Length (mm) | 1900 |
| Height (mm) | 1326 |
| Weight (Kg) | 717 |
| Fuel Tank Capacity (l) | 101 |
Output values
Stendby power:
| kVA | kW | Engine Speed (rpm) |
|---|---|---|
| 75 | 60 | 1500 |
Power:
| kVA | kW | Engine Speed (rpm) |
|---|---|---|
| 68.1 | 54.5 | 1500 |
Diesel engine
State-of-the-art engine brands that comply with ISO 8528, ISO 3046, BS 5514, DIN 6271 standards, have low fuel consumption, are mounted on the fuel pump, and have mechanical or electronic type governors are used.
| Brand | Yang Dong |
| Model | YD4EZLD |
| Air Intake System | Turbocharger, Intercooler |
| Cylinder capacity (l) | 4.1 |
| Cylinder Array | inline-four |
| Bore x Stroke (mm*mm) | 105*118 |
| Governor Type | Mechanical/Electronic |
Dimensions and weight
Enclosed Group:
| Width (mm) | 950 |
| Length (mm) | 2300 |
| Height (mm) | 1560 |
| Weight (Kg) | TBA |
| Fuel Tank Capacity (l) | 85 |
Open Group:
| Width (mm) | 950 |
| Length (mm) | 2000 |
| Height (mm) | 1310 |
| Weight (Kg) | TBA |
| Fuel Tank Capacity (l) | 85 |
Output values
Stendby power:
| kVA | kW | Engine Speed (rpm) |
|---|---|---|
| 100 | 80 | 1500 |
Power:
| kVA | kW | Engine Speed (rpm) |
|---|---|---|
| 90.9 | 72.7 | 1500 |
Diesel engine
State-of-the-art engine brands that comply with ISO 8528, ISO 3046, BS 5514, DIN 6271 standards, have low fuel consumption, are mounted on the fuel pump, and have mechanical or electronic type governors are used.
| Brand | Yang Dong |
| Model | Y4110ZLD |
| Air Intake System | Turbocharger, Intercooler |
| Cylinder capacity (l) | 4.4 |
| Cylinder Array | inline-four |
| Bore x Stroke (mm*mm) | 110*118 |
| Governor Type | Mechanical/Electronic |
Dimensions and weight
Enclosed Group:
| Width (mm) | 950 |
| Length (mm) | 2650 |
| Height (mm) | 1660 |
| Weight (Kg) | TBA |
| Fuel Tank Capacity (l) | 160 |
Open Group:
| Width (mm) | 950 |
| Length (mm) | 2350 |
| Height (mm) | 1400 |
| Weight (Kg) | TBA |
| Fuel Tank Capacity (l) | 160 |
Output values
Stendby power:
| kVA | kW | Engine Speed (rpm) |
|---|---|---|
| 110 | 88 | 1500 |
Power:
| kVA | kW | Engine Speed (rpm) |
|---|---|---|
| 100 | 80 | 1500 |
Diesel engine
State-of-the-art engine brands that comply with ISO 8528, ISO 3046, BS 5514, DIN 6271 standards, have low fuel consumption, are mounted on the fuel pump, and have mechanical or electronic type governors are used.
| Brand | Yang Dong |
| Model | YD4110ZLD |
| Air Intake System | Turbocharger, Intercooler |
| Cylinder capacity (l) | 4.3 |
| Cylinder Array | inline-four |
| Bore x Stroke (mm*mm) | 110*118 |
| Governor Type | Electronic |
Dimensions and weight
Enclosed Group:
| Width (mm) | 950 |
| Length (mm) | 2650 |
| Height (mm) | 1660 |
| Weight (Kg) | TBA |
| Fuel Tank Capacity (l) | 160 |
Open Group:
| Width (mm) | 950 |
| Length (mm) | 2350 |
| Height (mm) | 1400 |
| Weight (Kg) | TBA |
| Fuel Tank Capacity (l) | 160 |
Output values
Stendby power:
| kVA | kW | Engine Speed (rpm) |
|---|---|---|
| 125 | 100 | 1500 |
Power:
| kVA | kW | Engine Speed (rpm) |
|---|---|---|
| 113 | 90 | 1500 |
Diesel engine
State-of-the-art engine brands that comply with ISO 8528, ISO 3046, BS 5514, DIN 6271 standards, have low fuel consumption, are mounted on the fuel pump, and have mechanical or electronic type governors are used.
| Brand | Yang Dong |
| Model | YD4GZLD |
| Air Intake System | Turbocharger, Intercooler |
| Cylinder capacity (l) | 4.3 |
| Cylinder Array | inline-four |
| Bore x Stroke (mm*mm) | 110*118 |
| Governor Type | Electronic |
Dimensions and weight
Enclosed Group:
| Width (mm) | 950 |
| Length (mm) | 2650 |
| Height (mm) | 1660 |
| Weight (Kg) | TBA |
| Fuel Tank Capacity (l) | 160 |
Open Group:
| Width (mm) | 950 |
| Length (mm) | 2350 |
| Height (mm) | 1400 |
| Weight (Kg) | TBA |
| Fuel Tank Capacity (l) | 160 |
